　The GE Fanuc IC693MDL740 is a Series 90-30 module. This module is a positive logic output module that features Sixteen (16) sourcing output with 0.5 Ampere capacity per channel. This module has an operating voltage range of 12 to 24 volts DC (+20%, –15%). It has Two (2) groups of output with Two (2) channels per group.　

　Product Description

　　IC693PWR330 is a High Capacity Power Supply with 30 watts output and 120/240 VAC/125 VDC Input. There are applications that might need high +5V current capacity which may not be present with the standard supply(IC693PWR321).Therefore, this high capacity power supply permits each one of the 30 watts to be utilized from the +5V supply. IC693PWR330 can function from an input voltage source within the range of 85 to 264 VAC or 100 to 300 VDC. This power supply offers a +5 VDC output, +24 VDC Relay power outputs which distribute power to circuits on Series 90-30 Output Relay modules. An Isolated +24 VDC utilized internally by some modules may be used to offer external power for 24 VDC Input modules. IC693PWR330 has field Wiring Connections for the AC/DC Input Power Supplies. These two power supplies consist of 6 terminals used for user link up. These links include; AC Power Source, 20 VAC power source, and ground wires from the 240 VAC power source. They are attached to the system via the top 3 terminals on the front of the power supply. Their sensitivity to an AC/DC input power supply is normally low.

　　IC693PWR330 contains input overvoltage protection devices which have an internal connection on pin 4 found on the user terminal strip. This pin is linked to pin 3 with the offered strapped jumper that is well set up at the company. The strapped jumper can be removed to make the character nonfunctional in case overvoltage protection is not needed from both pins 3 and 4. It also requires overcurrent protection which is offered by the 5V logic output which is electronically limited to 3.5 amps (7 amps for high capacity supplies). Whenever there is excess load it is sensed on the inside which may lead to shutting down of the power. An internal fuse in the input acts as a power back up in case of such occurrences. It also safeguards the power supply from internal supply faults.

　　The IC693MDL740 is a GE Fanuc Series 90-30 Programmable Logic Controller (PLC) module. This module is a Positive Logic Output module, specifically, sourcing current to the connected loads from the module common or positive power bus. It has Two (2) groups of Eight (8) channels each, with each channel rated at 0.5 Ampere load.

　　The IC693MDL740 has front panel LED indicators, located on top of the module. These LEDS individually represent the actuated state of each of the module’s channels as well as the operational state of the module. Being a sourcing output module, each channel of this module is capable of energizing common electrical loads such as contactors, relays, pilot lamps, buzzer, horn and other D24 VDC powered devices. This module does not come with internal fusing thus, to further protect the module, external fuses may be installed.

　　The IC693MDL740 is installed to any available slot of a 5-slot or 10-slot Series 90-30 baseplate. As long the controller has the sufficient memory to accommodate this 16-point output module, the number of module instances varies.

　　The IC693MDL740 rated voltage is 12/24 volts DC with operating voltage range of 12 to 24 volts DC (+20%, –15%). The output characteristics of this module include an inrush current of 4.78 amps for 10 ms, maximum output voltage drop of 1 VDC, Off-state leakage current of 1 mA, ON response time of 2 ms, maximum and OFF response time of 2 ms, maximum. This module has a power consumption of 110 mA (all outputs on) from 5 volt bus on backplane.

　　The IC693MDL740 module is a 12 to 24 Volts DC rated positive logic output module. There are 16 output points in 2 groups of 8 with a common power output terminal for each group. The IC693MDL740 module has positive logic characteristics acting as a current source to loads from user common and positive power bus. The output device is connected between the negative power bus and the module output. The IC693MDL740 module is compatible with multiple load devices, including solenoids and motor starters. The output voltage range for the module is 12 to 24 Volts DC. The maximum output current per module point is 0.5 Amps and the maximum output current per common is 2 Amps. The respective maximum on and off response times are 2 milliseconds. The rated inrush current for 10 milliseconds duration is 4.78 Amps.

　　FAQ for IC693MDL740

　　What is the rated output current per channel of the IC693MDL740 module?

　　The module’s rated output current is 0.5 Ampere.

　　What is the maximum output current per group?

　　The maximum output current per group is 2 Ampere.

　　How many output groups does the IC693MDL740 have?

　　The IC693MDL740 has Two (2) output groups.

　　Technical Description of IC693MDL740

　　The GE IC693MDL740 module is a digital I/O module. There are 16 output points on the IC693MDL740 digital I/O module.
