GE WES13-3 D20 D200 Substation Controller
D200 Chassis (multiple-slot, VME] The D200 chassis is equipped with a rear-mounted termination board forpower connections and serial-port access.
Many products have not been listed yet. For more products, please contact us
If the product model is inconsistent with the displayed image, the model shall prevail. Please contact us for specific product images, and we will arrange for photos to be taken and confirmed in the warehouse
We have 16 shared warehouses worldwide, so sometimes it may take several hours to accurately return to you. We apologize for any inconvenience caused. Of course, we will respond to your concerns as soon as possible.
MultilinD20/D200 Substation Controllers Simple to Advanced Substation Automation Control The Multilin D20/D200 Substation Controllers offer an industry leading design embedded with high value substation automation applications that provide cost savings, increased reliability, and improved operational efficiencies in electric power substations. The ability to support a wide range of communication protocols and applications,
allows
the D20 to be interoperable with a broad range of intelligent electronic slave
and master devices. The D20 can execute simple to complex local logic, compile
and process data [collect and convert] and reports upstream to master stations.
The D20’s distributed, expandable I/O architecture
and mission-critical automation control applications reinforce why the D20
controller is being used in over 40,000 installations around the world. Key
Benefits In a mission-critical substation-hardened package, the D20/D200
provides:https://www.axcontroler.com/
•Substation
client and server functionalities by maintaining a distributed architecture for
gathering and controlling data on substation equipment while sending data to
master stations via serial RS-232, RS-485, fibre optic or Ethernet interfaces
for point to point, multi-drop and remote connections.
•Support for a broad
range of SCADA host protocols, IED protocols, Communication options,
Input/output (I/O) peripheral modules, and operation and maintenance utilities
substation automation applications. Refer to the hardware manual and see the
appendix section of this document for more details. Applications Functionalities
such as data concentrator, protocol converter or a local automation platform to
implement popular distribution automation applications such as capacitor bank
control, outage prevention programs, feeder resource optimization and control
interlocking inhibition and subgrouping. Functionalities such as data
concentrator, protocol converter or a local automation platform to implement
popular distribution automation applications such as capacitor bank control,
outage prevention programs, feeder resource optimization and control
interlocking inhibition and subgrouping.
•Data
Concentrator Automatically consolidates collected information from intelligent
electrical devices (IEDs), such as relays and meters, and communicates to SCADA,
EMS, DMS and Data Historian systems
•Protocol Converter Translates different
data message formats between devices to support interoperability
•Local
Automation Platform Implements popular distribution automation applications such
as capacitor bank control, outage prevention programs, feeder resource
optimization and control interlocking, inhibition and subgrouping
Substation Controller Connectivity
The D20/D200 can
support a wide range of substation automation communication protocols and
enhanced SCADA applications. See Appendix B for a list of supported protocols
for both client and server devices. The following summarizes some of the
different data translation applications that are equipped in the D20/D200.
Multilin D20/D200 Data
Translation Applications User Programmable Logic:
•LogicLinxmodule:
IEC61131-3 compliant PLC-type logic with full support for 5 programming
languages
•Calculator module: Soft logic utility to perform mathematical and
logical operations Generation, Transmission, and Feeder
Bay Automation Applications: •
Automatic Voltage Control module: Maintains steady voltage base on user-defined
targets and settings
•Local /
Remote Data Translation module:A master local/remote switch to
control the local/remote state of distributed devices
•Secondary
Master Trip/Close module:Enables the use
of individual relays (with external terminations) as master trip/close
relays
•Set-point
Adjustment module: Adjust set points based on control request durations or
analog input values
•Tap Position Indication module: Translates status points
into scaled analog input values to reflect transformer tap
positions Distribution
Automation Applications:
•Auto Reclose: Automatically reclose
tripped circuit breakers following momentary faults
•Automatic Restoration:
Patented load transfer scheme isolates faults and restores power to non-faulted
sections if possible
•Distribution Capacitor Control
Algorithm:Improves reactive support during peak periods through
more effective use of existing capacitor banks
•Fault Localization:Locates
and isolate faults to reduce customer outage times
•Load and Dead Bus
Transfer:Monitors a network of substations and move load off
overloaded transformers to other stations as required
•Load
Shedding/Curtailment:Sheds load intelligently during overload
conditions Data Logging / Storage Applications:
•SOE Local Logger:Logs
digital and analog SOEs to an external printer, PC or to a CSV file
•Accumulator
Freeze:Coordinates freezing of accumulator groups
•Event Storage:Stores
history of current values, status, and time-tags of analogs and accumulators for
up to 7 days
•Historical
Analog:Stores averaged historical values for up to 8 analog
inputs Communication Services Applications:
•Communication
Watchdog:Monitors and report the health of
communications
•Substation
Maintenance:Suppresses SCADA point reporting during substation
maintenance
•Virtual
Terminal:Directs remote access to connected devices
•Line Switch:Monitors main
and secondary communication channels and retransmits on a third channel
•LAN Services:TFTP, SPT
Server/Client, Time Server/Client
•COM Statistics:Records a
detailed communication pass/fail statistics
•IRIG B Source:Time sync
connected devices using IRIG-B
•SNTP Client:Time sync over
an Ethernet LAN Data Reduction and Summarizing Applications:
•Analog Reference:Monitors
analog input hardware for good or bad reference values
•Data Change Detect:Toggles
a status point every time any data in a configured group changes
•Alarm Prioritization:An
alarm filter designed to manage the 3 level alarms reported by GE’s DART
pole-top/pad-mount distribution RTU
•Analog Averaging:Averages
analogs at regular intervals
•General Alarm:Groups alarms
together to create summary alarms
•Top of Hour (TOH) Analog
Averaging:Averages analogs at regular intervals relative to the
top of the hour • Redundant I/O: Provides data from a backup source if the
primary source is off-line Data Conversion Applications:
•Digital-Analog Value
Conversion:Converts digital input groups to analog data using
binary, BCD, or gray code encoding
•Digital Input to
Counter:Counts the number of SOE or COS transitions on status
points
•BCD
Setpoint:Translates analog output requests into a group of BCD
encoded control points • Accumulator Delta to Analog: Converts accumulators to
analog values for protocols that do not support counters
•Time Stamp:Interprets each
bit in an analog input as a status point, and create SOEs appropriately
•Analog to Digital
Conversion:Converts analog inputs into groups of binary coded
control outputs
•Mailbox:Converts analog
outputs into analog inputs so they can be read by all masters
https://www.axcontroler.com/
Configuration
and Maintenance Facility The D20/D200 is equipped with a range of maintenance
utilities to assist the user in configuring, testing and monitoring the system.
ConfigPro ConfigPro is a tool, installed on a personal computer, which helps you
manage information associated with your GE Energy equipment. The primary use of
ConfigPro is to facilitate the configuration of D20/D200 hardware and software
through the maintenance port on the main processor and I/O peripheral.
Information is accessed through a hierarchy of windows, as
follows:
Project Window:Provides a graphical representation
of your project. Each device in the project is represented by a corresponding
icon. Connections between devices are shown by a series of lines and
arrows.
Device Window:When you double-click on a device, the
device window is opened in the main area. The device window will display all of
the configurable applications for the device.
The device window has four
tabs:
•Data collection applications
•Data
translation applications
•System point database
applications
•Data
processing applications Application Window:Displays the tables
for a particular application Report Window: Allows you to select and print
reports. SGConfig SGConfig is the latest software used to
configure D20/D200.
SGConfig replaces ConfigPro because it supports Windows 7 - 32 and 64-bit
operating systems while maintaining backwards compatibility with Windows XP. It
is a PC software-based user interface that allows users of GE Substation
Gateways to efficiently manage configuration files for the RTUs series of
Substation controllers. SGConfig includes all of the functionality available in
the ConfigPro software, provides enhanced visual representation of your
substation hardware configuration and device software configuration. In addition
to the ConfigPro functionality, SGConfig provides support
for::
•Importing
and exporting xml representation of D2x devices
•D25 KT control card
•D25
Ethernet 100/10 MB card
•Secure configuration transfer to/from D20 devices
with D20MX processors over Ethernet connections.
